GCr15SiMn Single Row Cylindrical Roller Bearing Industrial For Automotive

Place of Origin China
Brand Name DJTech or OEM, TNT, SKF, Koyo ,FAG , NSK,INA,IKO,TIMKEN
Certification ISO9001-2015/SGS/BV/CE/IAF
Model Number NU series ,NNU series ,NN series
Minimum Order Quantity 10
Price Negotiable
Delivery Time about 3~4wks
Payment Terms T/T in advance
Supply Ability 7.5KKPCS/Month

Contact me for free samples and coupons.

WhatsApp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Service OEM, Customized Lubrication Oil Lubrication, Grease Lubrication
Weight 2.96-50.2kg Seals Type Open, Z, ZZ, RS, 2RS
Vibration Level V1, V2, V3, V4 Number Of Row Single Row, Double Row, Three Row , Four Row
Outer Diameter 180-400mm Clearance C0, C2, C3, C4, C5
High Light

GCr15SiMn Cylindrical Roller Bearing

,

Cylindrical Roller Bearing Industrial

,

Automotive Single Row Cylindrical Roller Bearing

Leave a Message
Product Description

GCr15SiMn Single Row Cylindrical Roller Bearings For Heavy-Duty Applications , TNT

Product Description:



Single Row cylindrical roller bearings are generally only used to bear a larger radial load,because its roller and ring raceway is line contact, compared to radial ball bearings of the same size,Its radial load capacity is larger ( rise 1.5~3 times), Impact resistance, good rigidity, but generally not used to withstand axial load .



Cylindrical Roller Bearings are one of the most widely used rolling bearings. They are suitable for high-speed operations and offer a high radial load capacity. These bearings are composed of an inner ring, outer ring, and a cage that houses and evenly spaces the rollers. Their design makes them suitable for high radial loads and for applications that require high accuracy and stiffness. Our Cylindrical Roller Bearings are made with high quality materials such as GCr15SiMn, GCr15, Chrome Steel, and Carbon Steel and are available in outer diameters ranging from 35 to 420 mm and bore diameters from 15 to 200 mm. We also offer a variety of seals such as open, Z, ZZ, RS, and 2RS. We provide customizedservice for our Cylindrical Roller Bearings, including TNT Combined Needle Roller Bearings, FAG Spherical Roller Bearing, and INA Cylindrical Roller Thrust Bearings.



Technical Parameters:





Dimension Rated load Model# Weigh Maximum speed
mm kN Current model Original model kg r/min
d D B Fw Ew rmin Cr Cor Grease Oil
120 180 28 135 - 2 130 168 NU 1024M 32124H 2.96 3400 4000
  180 28 135 - 2 130 168 NJ 1024 42124 3.09 3400 4000
  215 40 - 192 2.1 250 211 N 224E 2224H 6.2 2400 3000
  215 40 144 - 2.1 322 422 NU 224E 32224H 6.2 2400 3000
  215 40 144 - 2.1 322 422 NJ 224E 42224H 6.2 2400 3000
  240 80 150 - 3 477 408 NJ 624 42724 17.8 2400 3200
  260 86 154 - 3 632 868 NU 2324E 32624 23.8 1900 2400
  310 72 - 260 5 660 530 N 424 2424 29 1900 2400
  310 72 170 - 5 642 772 NU 424 32424 29.1 1900 2400
  310 72 170 - 5 642 772 NJ 424 42424 29.1 1900 2400
130 200 33 148 - 2 152 212 NU 1026 32126 3.84 3200 3800
  250 80 158 - 3 547 473 NJ 626 42726 18.7 2200 3000
  280 58 - 243 4 515 410 N 326E 2326 17.8 1800 2200
  280 58 167 - 4 492 620 NU 326E 32326 17.9 1800 2200
  280 58 167 - 4 492 620 NJ 326E 42326 18.2 1800 2200
  280 93 - 243 4 770 685 N 2326 2626 29 1800 2200
  280 93 167 - 4 748 1060 NU 2326 32626 28.7 1800 2200
  280 93 167 - 4 748 1060 NJ 2326 42626 29 1800 2200
  340 78 185 - 5 782 942 NU 426 32426 41.5 1500 1900
  340 78 185 - 5 782 942 NJ 426 42426 41.7 1500 1900
140 190 24 - 178 1.5 126 190 N1928 - 2 3200 3800
  190 24 154 - 1.5 126 190 NU1928 - 1.98 3200 3800
  210 33 158 - 1.1 190 270 NU1028 32128 3.87 2400 3000
  250 68 169 - 3 500 730 NU2228 - 14.7 2000 2600
  250 68 169 - 3 438 700 NJ 2228 42528 17 2000 2600
  300 62 - 260 4 545 690 NF 328 12328 21.8 1800 2200
190 260 42 208 - 2 239 216 NU 2938 2E+06 6.45 2000 2800
  290 46 215 - 2.1 395 595 NU1038 32138 11 2000 2800
  340 55 - 302 4 630 830 N238 2238 22.9 1600 1900
  340 55 231 - 4 512 745 NU 238 32238 21.6 1600 1900
  340 55 231 - 4 512 745 NJ 238 42238 22 1600 1900
  340 92 - 299 4 910 1400 N2238 - 38.6 1600 1900
  340 92 231 - 4 975 1570 NU 2238 32538 38.6 1600 1900
  400 78 - 345 5 882 1190 N 338 2338 50.2 1200 1500



Applications:



Cylindrical Roller Bearings are widely used in many industries, such as automotive, agriculture, construction, and machinery. They are commonly used in applications such as conveyor systems, pumps, compressors, motor shafts, and gearboxes. DJTech Cylindrical Roller Bearings are available in the NU series, NNU series, and NN series. Our bearings are manufactured to the highest quality standards, and are certified to ISO9001-2015/SGS/BV/CE/IAF. We offer brands such as TIMKEN, NSK, Koyo, FAG, INA, IKO, and SKF. Cylindrical Roller Bearings are available in steel, brass, and nylon cages, with precision levels of P0, P6, P5, and P4. Bore diameters range from 15mm to 200mm, and clearance levels from C0 to C5. Vibration levels from V1 to V4 are available. We offer competitive prices and a minimum order quantity of 10. Delivery time for our Cylindrical Roller Bearings is typically 3~4 weeks, and payment terms are T/T in advance. We can supply up to 7.5KKPCS/Month.



Customization:



1. Brand Name: DJTech or OEM, TNT, SKF, Koyo ,FAG , NSK,INA,IKO,TIMKEN

2. Model Number: NU series ,NNU series ,NN series

3. Place of Origin: China

4. Certification: ISO9001-2015/SGS/BV/CE/IAF

5. Minimum Order Quantity: 10

6. Payment Terms: T/T in advance

7. Supply Ability: 7.5KKPCS/Month

8. Cage: Steel Cage, Brass Cage, Nylon Cage

9. Outer Diameter: 180-400mm

10. Number of Row: Single Row, Double Row, Three Row , Four Row

11. INA Cylindrical Roller Thrust Bearings



FAQ:

Q1: What is Cylindrical Roller Bearing?
A1: Cylindrical Roller Bearing is a kind of rolling-element bearing that uses cylinders as the rolling elements. It is mainly used to support radial loads and is suitable for high-speed applications. Q2: What brand of Cylindrical Roller Bearing do you offer?
A2: We offer DJTech or OEM, TNT, SKF, Koyo ,FAG , NSK,INA,IKO,TIMKEN Cylindrical Roller Bearing. Q3: What types of Cylindrical Roller Bearing do you offer?
A3: We offer NU series ,NNU series and NN series Cylindrical Roller Bearing. Q4: What is the minimum order quantity?
A4: The minimum order quantity is 10. Q5: What is the delivery time?
A5: The delivery time is about 3~4wks.
