FAG 7003 Angular Contacted Ball Bearing Inner Diameter 17mm 7.3 KN Dynamic Load

10
MOQ
$3.5~350.00
Price
FAG 7003 Angular Contacted Ball Bearing Inner Diameter 17mm 7.3 KN Dynamic Load
Features Gallery Product Description Request A Quote
Features
Specifications
Rated Static Load (Cor): 4.45 KN
Rated Dynamic Load(Cr): 7.3 KN
Max. Limited Speed For Oil Lubrication: 41000 R/min
Grease Lubrication: 31000 R/min
Model: 7003
Type: Angular Contact Ball Bearing
Clearance: C5,C4,C3,C0 ,C2
Width: 10 Mm
Highlight:

FAG 7003 Angular Contacted Ball Bearing

,

17mm Angular Contacted Ball Bearing

,

7.3 KN Angular Contacted Ball Bearing
Basic Infomation
Place of Origin: Germany, Sweden
Brand Name: SKF , FAG , INA
Certification: ISO9001-2015/SGS
Model Number: 7003
Payment & Shipping Terms
Packaging Details: Standard packing
Delivery Time: based on stock
Payment Terms: T/T in advance
Supply Ability: 7.5KKPCS/Month
Product Description
FAG 7003 Angular Contact Ball Bearing Inner Diameter 17mm 7.3 KN Dynamic Load
Key Specifications
Rated static load (Cor) 4.45 KN
Rated dynamic load (Cr) 7.3 KN
Max. speed (oil lubrication) 41000 R/min
Max. speed (grease lubrication) 31000 R/min
Model 7003
Type Angular Contact Ball Bearing
Clearance options C5, C4, C3, C0, C2
Width 10 Mm
Product Description
The FAG 7003 Angular Contact Ball Bearing is engineered to simultaneously handle both radial and axial loads, making it ideal for demanding industrial applications. With an inner diameter of 17mm and outer diameter of 35mm, this compact bearing offers efficient performance in space-constrained environments.
This precision bearing features a 60-degree contact angle and is constructed from high-quality steel for maximum durability. The 7003 model is designed for high-speed operation with low friction, delivering reliable performance in machine tools, pumps, compressors, and automotive/aviation applications.
Technical Parameters
Material Steel
Cage material Steel or Brass
Precision grades P0, P6, P5, P4, P2
Lubrication options Grease, Oil
Net weight 0.045 Kg
Support & Services
Our technical team provides comprehensive support for installation, maintenance, and troubleshooting. We offer bearing analysis and failure diagnosis services to ensure optimal performance and extended product life.
Custom solutions are available in various sizes and materials to meet specific application requirements. Contact us to discuss your project needs.
